Product News October 21, 2020

Making high-quality vision systems affordable

news photo - Harrier 10x AF-Zoom Camera with LVDS, HDMI, USB or 3G-SDI output

In response to requests for a low-cost autofocus-zoom block camera, we’ve added a new high-quality and cost-effective addition to our product range. The Harrier 10x AF-Zoom Camera is now available with LVDS/EX-SDI, USB 3/HDMI and 3G-SDI video output options. With our advanced Harrier technology, it delivers flexible, robust and cost-effective image processing.

Features of the Harrier 10x AF-Zoom Camera

  • 1/3″ 2MP progressive scan CMOS sensor.
  • 1080p – 60/50/30 fps, 720p – 60/50/30 fps.
  • 10x Optical Zoom & 32x Digital Zoom.
  • Day & Night mode – Infrared Cut filter Removal (ICR).
  • Real-time True Wide Dynamic Range (WDR).
  • Digital Noise Reduction (2D+3D DNR).
  • Compact size and low power requirement.

The LVDS/EX-SDI camera supports VISCA and Pelco-D/P Control Protocols, while the USB/HDMI version supports UVC, USB VISCA and serial VISCA control protocols. The 3G-SDI module also offers HD-VLC™ technology for video transmission over extremely long cable lengths and slip rings.

Applications

Due to their very compact size, high resolution and autofocus-zoom functionality, the cameras are particularly well-suited to surveillance, remote monitoring, aerospace, digital microscopy and medical applications.

View the range of our autofocus-zoom block cameras online and contact us to find out which module will be best suited to your computer vision needs.
