ActiveSDK, software development kit for FireBird frame grabbers

Click image to enlarge

ActiveSDK Software Development Kit

Part Number: AS-ACTIVESDK-xxx (xxx = WIN, LIN or QNX)

  • Supports Active Silicon CoaXPress and Camera Link frame grabbers.
  • Comprehensive library functions and documentation.
  • Supported environments include 64-bit Windows, Linux and QNX.
  • Common API across all supported operating systems.
  • Comprehensive suite of C, C++ and C# example applications with full source code.
  • GenICam and NVIDIA GPUDirect for Video™ examples provided.
  • Libraries are supplied as Windows dynamic link libraries (.dll) and Linux shared object (.so) libraries.
Enquire About This Product
  • Description

  • Downloads

  • Ordering Info



Ordering Info

ActiveSDK is designed for OEMs and integrators using FireBird frame grabbers. It contains comprehensive example applications and optimized libraries for a variety of operating systems. The API (application programming interface) is consistent across operating systems and hardware platforms allowing easy migration.

ActiveSDK provides components to develop applications using:

  • PHX library (PHX) – provides setup, acquisition and control features.
  • Active Display Library (ADL) – allows captured buffers to be displayed easily (Windows only).
  • Active Image Processing Library (TMG) – provides image file open/save, image format conversion (e.g. Bayer to RGB), JPEG compression and other image processing functions.
  • Active Browser – provides a widget that can display any number of GenApi nodemaps, each in their own tab. The Active Browser library also provides a way to integrate the widget within an MFC program (Windows only).
  • GenTL Producer – GenICam compliant driver package.
  • GPUDirect for Video™ – accelerated acquisition and processing, including DMA directly to the GPU.

The core libraries provide a highly optimized, efficient and reliable environment for the development of very high-speed and demanding image applications. Comprehensive documentation is provided for all parts of the SDK, including Developer’s Guides and application examples with full source code.

Supported Development Environments

  • Windows 11 (64-bit), Windows 10 (64-bit) – support for Visual Studio 2008 and onwards.
  • Linux (64-bit) – GNU Compiler Collection (relevant to particular Linux distribution).
  • For QNX Neutrino RTOS v6.5, v6.6 and v7.0 – OEM use only, contact Active Silicon for quotation.
Download File Type File Size


Datasheet ActiveSDK Software Development Kit pdf 177.01 KB

Ordering Information

Part number Description


Software Development Kit for Windows (64-bit) operating system.


Software Development Kit for Linux (64-bit) operating system.


Software Development Kit for QNX operating system – contact Active Silicon for details.
