Harrier 30x AF-Zoom HDMI Camera (Sony FCB-EV7520/EV7520A)

Part Number: AS-CIB-HDMI-001-7520-A | AS-CIB-HDMI-001-7520A-A

Legacy Product

Product photo HDMI Autofocus-Zoom Block Camera with Sony FCB EV7520A

Legacy Product

Features

HDMI camera solution with Sony FCB-EV7520/EV7520A.
30x optical zoom, 12x digital zoom.
1/2.8”-type Exmor R CMOS progressive scan image sensor.
STARVIS back-illuminated pixel technology.
Supports all HD modes up to 1080p60.
Camera control using VISCA™ protocol over TTL serial.
Video output mode selected by DIP switches or VISCA control.

Enquire About This Product

The Sony FCB-EV7520 and -EV7520A cameras are now end-of-life. Please contact sales for remaining stock and alternative products. We recommend the Harrier 30x AF-Zoom HDMI Camera (Sony FCB-EV9520L) as their improved successor.

The Harrier 30x AF-Zoom HDMI Camera (Sony FCB-EV7520 or -EV7520A) offers 30x optical zoom and 12x digital zoom with HDMI output. The video output is SMPTE 274M and SMPTE 296M compliant and all HD modes up to 1080p60 are supported.

Based on the Sony FCB-EV7520 or FCB-EV7520A camera with a back-illuminated CMOS sensor, the camera guarantees high-quality imaging even in low-light conditions. It builds upon the market leading specifications of Sony’s world-renowned FCB Series features including Advanced Noise Reduction, Auto ICR, Spherical Privacy Zone Masking and Wide Dynamic Range, which makes this camera solution suitable for a variety of demanding applications.

The HDMI output is enabled when an HDMI cable is connected. On power-up, the camera video mode may be selected by the DIP switch settings on the board. Camera video modes, along with other camera and interface board functions, may also be controlled by VISCA commands sent using TTL serial communication.

Alternatively, the Sony FCB-EF7520A camera is also available with USB, USB/HDMI, Ethernet IP or 3G-SDI video output.

Camera Features

Image sensor	1/2.8”-type Exmor R CMOS sensor
Number of effective pixels	2130K
Output pixels (H x V)	1920 x 1080, 1280 x 720
Video format	1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080i/60, 1080i/59.94, 1080i/50, 720p/60, 720p/59.94, 720p/50, 720p/30, 720p/29.97, 720p/25
Minimum illumination (50%, High Sensitivity mode ON)	ICR-Off mode: 0.01lx (shutter speed 1/30 sec), 0.0013lx (1/4 sec or 1/3 sec) ICR-On mode: 0.0015lx (shutter speed 1/30 sec), 0.0008lx (1/4 sec or 1/3 sec, 30%)
Minimum illumination (50%, High Sensitivity mode OFF)	ICR-Off mode: 0.1lx (shutter speed 1/30 sec), 0.013lx (1/4 sec or 1/3 sec) ICR-On mode: 0.006lx (shutter speed 1/30 sec)
Recommended illumination	100lx to 100,000lx
Gain	Auto / manual (0dB to 50.0dB, 0 to 28 steps)
Shutter speed	1/1 sec to 1/10,000 sec, 22 steps
Sync system	Internal
Exposure compensation	0dB to ± 10.5dB, 15 steps
Backlight compensation	Yes
Gamma	Standard / straight
Aperture control	16 steps
White balance	Auto, ATW, indoor, outdoor, one push WB, manual WB, outdoor auto, sodium vapor lamp (Fix / auto / outdoor auto)
AE (Auto exposure mode)	Full auto, manual, priority mode (shutter / iris), EV compensation, spot exposure, slow AE
Lens (wide to tele)	30x optical zoom f=4.3mm to 129mm, F1.6 to F4.7
Zoom mode	Standard mode / variable mode / direct mode
Digital zoom	12x (max 360x with optical zoom)
Zoom movement speed - optical wide to optical tele	5.0 sec (focus tracking ON), 2.5 sec (focus tracking OFF) [FCB-EV7520A] 4.6 sec (focus tracking ON), 3.2 sec (focus tracking OFF) [FCB-EV7520]
Zoom movement speed - optical wide to digital 12x tele	7.0 sec (29.97p / 59.94p), 7.4 sec (25p / 50p) [FCB-EV7520A] 6.7 sec (29.97p / 59.94p), 7.1 sec (25p / 50p) [FCB-EV7520]
Zoom movement speed - digital wide to digital 12x tele	2.1 sec (29.97p / 59.94p), 2.5 sec (25p / 50p) [FCB-EV7520A] 2.2 sec (29.97p / 59.94p), 2.7 sec (25p / 50p) [FCB-EV7520]
Focusing system	Auto focus (normal AF, interval AF, zoom trigger AF [sensitivity: normal, low]) Manual (standard, variable, direct), one push trigger, near limit, full scan one push trigger, IR correction
Horizontal viewing angle (1080p / 1080i mode) (wide to tele)	63.7° (Wide) to 2.3° (Tele)
Horizontal viewing angle (720p mode) (wide to tele)	63.7° (Wide) to 2.3° (Tele)
Minimum object distance	10mm (Wide) to 1200mm (Tele)

Connector Specifications

KEL30 Connector (J1)	The interface board is fitted with a 30-way miniature connector to link to the matching connector on the camera. Connector type: KEL USL00-30L. Mating cable: A 30-way micro coaxial cable (AS-CIB-USL30-100MM) is supplied with the camera. Lengths available: KEL USL20-30SS-010-C (100mm length) or KEL USL20-30SS-005-C (50mm length).
Input/Output Connector (J2)	The interface board is fitted with an industry standard 4-way connector for VSync signal output and test pattern/reset control inputs. Connector type: JST SM04B-SRSS-TB Mating cable: A suitable cable is available as part of the cable kit AS-CIB-CBLKIT-003-A (see ordering information tab). See Harrier HDMI Camera Interface Board datasheet (download tab) for pin assignments and control options.
Power and Control Connector (J3)	The interface board is fitted with an industry standard 10-way connector for power and serial control. Connector type: JST SM10B-SRSS-TB Mating cable: A suitable cable is available as part of the cable kit AS-CIB-CBLKIT-003-A (see ordering information tab). See Harrier HDMI Camera Interface Board datasheet (download tab) for pin assignments and control options.
JTAG Connector (J4):	Test connector used in manufacturing for circuit verification.
HDMI Output Connector (J5)	The interface board on the camera is fitted with a micro HDMI display output connector. HDMI output is active when an HDMI cable is connected. Connector type: HDMI Type D (micro). Mating Connector: Standard micro HDMI cable.
Video Mode DIP Switch (SW1)	The interface board is fitted with an 8-way DIP switch (SW1) to enable selection of camera video format on power-up. Switches 5-8 are reserved for future use. See Harrier HDMI Camera Interface Board datasheet (download tab) for the configuration of the DIP switch elements.
Status LED	The interface board is fitted with a multi-color LED to indicate camera status.

Camera Functions

Auto ICR	Yes
Wide-D	Yes
Visibility enhancer	Yes
Defog	Yes (low / mid / high)
Noise reduction	Yes (3D + 2D / independent setting (3D, 2D)
Image stabilization	Yes
StableZoom	Yes
Flicker reduction	Yes (FCB-EV7520A only).
Spot light avoidance	Yes (FCB-EV7520A only).
Digital output	Yes
Motion detection	Yes
Spherical privacy zone masking	Yes
Alarm	Yes
Slow AE response	Yes
Picture effects	Black & white (monochrome image)
Picture freeze	Yes
Electronic flip (e-flip)	Yes
Mirror image	Yes
Slow shutter	Yes
Temperature readout	Yes
Title display	Yes (20 characters / line, max. 11 lines)
Camera mode display	Yes (English)

Physical and Environmental Details

Power requirements	8.25V to 12V DC
Power consumption	3.5W – Typical power with static view at 1080p60, values will vary with camera mode and with camera focus/zoom motor operations.
Operating temperature	0°C to +60°C (ambient environment).
Storage temperature	-20°C to +60°C
Relative humidity	20% to 80% non condensing (operating and storage)
Dimensions (L x W x H)	114 x 50.0 x 62.0mm
Weight	ca. 282g

Interface

HDMI

HDMI output is enabled when an HDMI cable is plugged in. The video mode of the HDMI output is the same as the output of the camera. To change the mode of the HDMI output the mode of the camera should be changed using VISCA serial commands or DIP switch settings (and power cycling). Video modes up to 1080p60 are supported.

Compliant with HDMI specification v.1.4a.

Camera control interface

VISCA protocol (CMOS 5V level)
Baud rate: 9.6 kbps, 19.2 kbps, 38.4 kbps, 115.2 kbps, stop bit: 1-bit

	Download	File Type	File Size
Datasheets	Datasheet Harrier HDMI Camera Interface Board	pdf	702.90 KB
	Datasheet Sony FCB-EV7520 camera	pdf	2.19 MB
	Datasheet Sony FCB-EV7520A camera	pdf	1.22 MB
Manuals & Quick Start Guides	Sony FCB-EV7520 Technical Reference Manual	pdf	2.83 MB
	Sony FCB-EV7520A Technical Reference Manual	pdf	2.48 MB
	Harrier HDMI CIB Quickstart Guide - v1.6.0.s	pdf	553.70 KB
Software	Sony FCB-EV7520/EV7520A Camera Control Software v.5.1.0.2	zip	160.96 KB
CAD Drawings & Data	Sony FCB-EV7520A Camera Technical Drawing	jpg	701.08 KB
Other Downloads	Technical Note - Troubleshooting guide for Harrier camera interface boards	pdf	276.68 KB

Part number	Description
AS-CIB-HDMI-001-7520-A	Harrier 30x AF-Zoom HDMI Camera (Sony FCB-EV7520); includes 100mm 30-way micro-coax cable AS-CIB-USL30-100MM, 50mm available upon request. Please use the part number AS-CIB-HDMI-001-7520A-A for ordering the combination with the Sony FCB-EV7520A.
AS-CIB-USBHDMI-001-EVAL-A	Evaluation Kit for Harrier USB/HDMI, including the Harrier 30x AF-Zoom HDMI Camera (Sony FCB-EV7520A). The kit contains power supply, board cables (AS-CIB-CBLKIT-003-A), micro-coax cable (AS-CIB-USL30-100MM, for connecting camera with camera interface board) and the Harrier Evaluation Board with PC serial interface (via USB UART). Not included: Camera and camera interface board.
AS-SONY-FCB-EV7520	Sony FCB-EV7520 autofocus-zoom block camera.
AS-SONY-FCB-EV7520A	Sony FCB-EV7520A autofocus-zoom block camera.
AS-CIB-HDMI-001-A	Harrier HDMI Camera Interface Board. Board only, no cables included.
AS-CIB-CBLKIT-003-A	Cable kit for AS-CIB-HDMI-001-A containing cables for J2, J3, and J4 that connect to the Harrier Evaluation Board.
AS-CIB-USL30-100MM	30-way micro-coax cable for connecting the interface board to the camera. Length 100mm (Manufacturer: KEL, part number: USL20-30SS-010-C).
AS-CIB-USL30-50MM	30-way micro-coax cable for connecting the interface board to the camera. Length 50mm (Manufacturer: KEL, part number: USL20-30SS-005-C).
AS-CIB-BRK-007-A	Metal bracket, screws and spacers for mounting Harrier camera interface boards to Sony FCB-EV7520A camera.
